Introduction
Factory testing is the visible end of a longer engineering process. By the time representative material reaches the machine, the buyer and supplier should already agree on the controlled drawing, tube specification, process sequence, tooling scope, operator assumptions and acceptance method. A test cannot repair unclear requirements that were carried through the project.
The most reliable evaluations use decision gates. Each gate confirms that enough information is available for the next stage and records any remaining TBC items. This does not make every project identical. A standalone chamfering machine and a multi-operation bending cell have different risks, but both benefit from traceable inputs and agreed evidence.
Procurement teams should connect commercial milestones to technical deliverables. Manufacturing engineers should own the part definition and acceptance logic. The equipment supplier should explain assumptions, limits and required trials. Capabilities must remain conditional until the actual tube material, shape, outside diameter, wall thickness, bending radius, finished-part drawing and output target have been reviewed.
Evaluate the Project Through Clear Decision Gates
The first gate is application definition. The buyer submits released drawings when available, known variants, material data and production targets. The supplier reviews whether the request is complete enough for a concept. Missing inputs should be listed rather than silently filled with typical values.
The second gate is process concept. Each finished feature is assigned to an operation, and the likely sequence is documented. The review covers access, datum transfer, clamping, tool interference, material handling, inspection and changeover. Alternative sequences can be compared when they affect risk or flexibility.
The third gate is scope confirmation. The parties identify machine functions, tooling, loading equipment, guarding, gauges, documentation, training and interfaces. Common items and part-specific items should be separated. Exclusions should be visible, particularly for upstream or downstream equipment that may influence the final part.
The fourth gate is design release. Controlled part revisions, material ranges and acceptance characteristics are confirmed before dedicated tooling is finalized. If an open dimension can change the tool, the project should not treat it as a minor note. The owner and deadline for each TBC item should be recorded.
The fifth gate is build and internal verification. The supplier checks machine functions, safety-related scope, tooling installation, program logic and basic process behavior according to the agreed project. This stage prepares for part trials but should not be confused with buyer acceptance.
The sixth gate is sample trial and factory acceptance testing. Representative input material is processed under documented conditions. The parties observe the complete cycle, inspect defined characteristics and record results. Deviations are classified, assigned and closed through an agreed method.
The final gate covers release for shipment and site preparation. Open items, packing scope, foundation or utility needs, installation responsibilities, training and site acceptance expectations are confirmed. Shipment approval should refer to the agreed test record, not only to a verbal demonstration.
Define Factory Testing Before the Machine Is Built
A useful factory acceptance test, often called FAT, answers specific questions. Does the supplied scope match the agreement? Can the machine execute the required functions? Can representative parts be produced and inspected using the approved definition? Are documents, tools and interfaces present? The FAT should not rely on undefined ideas such as "good quality" or "normal speed."
Use this table to build the protocol:
| FAT element | Define in advance | Typical evidence |
|---|---|---|
| Test part | Part number, revision and variant | Drawing and labeled samples |
| Input material | Grade, shape, OD, wall thickness and condition | Material identification and trial stock record |
| Machine setup | Tool set, recipe and operator assumptions | Setup sheet and observation |
| Functional checks | Movements, controls and included options | Signed checklist |
| Part checks | Features, datums, tolerances and sampling | Measurement record or gauge result |
| Output review | Cycle boundary, quantity and interruptions | Timed run notes with conditions |
| Changeover | Parts, tools and steps included | Observed changeover record |
| Documentation | Manuals, lists and agreed files | Document register |
| Open items | Classification, owner and due date | Punch list with closure method |
The sample quantity should fit the purpose of the test. A short run may demonstrate operation and part formation, but it does not automatically establish long-term process performance. If capability studies, extended runs or special inspections are required, they should be explicitly scoped with the method, material quantity and responsibility.
Cycle time must also have a clear boundary. State the starting condition, finishing condition, loading method, operator tasks, inspection sampling and treatment of stops. Record material and part variant. This makes the result understandable without presenting it as a universal machine rate.
Use this pre-FAT checklist:
- Confirm the controlling drawing revision and approved model.
- Verify that trial material represents the agreed production input.
- Identify each tool and the part numbers it supports.
- Approve the measurement method and responsible inspector.
- Mark critical characteristics and functional datums.
- Define the complete cycle and operator tasks to be observed.
- Prepare changeover parts if changeover is in scope.
- List required documents, spares and accessories for inspection.
- Agree on how deviations will be recorded and classified.
- Name the people authorized to sign the test record.
- Separate shipment blockers from items that can close later by agreement.
- Record photo or video requirements only with appropriate authorization.
Common Mistakes
One mistake is scheduling the FAT before the final drawing, material or protocol is available. The team then spends test time debating requirements rather than checking the equipment. Readiness should be reviewed before travel, material shipment or formal witness testing.
Another mistake is using substitute tube without documenting the difference. A change in material grade, wall thickness, seam condition or outside dimension may alter the result. If substitution is unavoidable, record it and state which conclusions remain provisional.
Buyers sometimes inspect a sample with a method that was never shared with the supplier. Different datum setups or gauge forces can produce different readings. The drawing and FAT protocol should identify how each acceptance feature will be measured.
Do not treat an isolated automatic cycle as finished-part output. Loading, unloading, orientation, recipe selection, gauge checks and normal operator intervention should be included when they are part of the proposed production method.
Finally, avoid an open-item list without priorities or owners. A useful punch list states the issue, evidence required for closure, responsible party, due date and whether it blocks shipment. Informal comments are difficult to track once equipment leaves the factory.
Information Buyers Should Provide
Provide the technical package early and keep it under revision control:
- Tube material, grade and delivery condition
- Tube shape, including round, square, rectangular or special profile
- Outside diameter or outside section dimensions
- Wall thickness and expected material variation
- Bending radius, bend angles and spatial orientation
- Finished-part drawing with revision, datums and acceptance characteristics
- Required output stated over a defined period with operator assumptions
- Initial part family, forecast mix and changeover frequency
- Raw stock length, cut condition and surface requirements
- Hole, slot, notch, chamfer and end-form details
- Upstream and downstream process constraints
- Plant utility, layout and integration information
- Buyer-required inspection, documentation and traceability items
- Proposed FAT parts, sample quantity and approval roles
Also explain which requirements are mandatory, preferred or TBC. This classification helps the supplier identify decisions that affect machine architecture or dedicated tooling. When several stakeholders are involved, nominate one controlled source for drawings and one owner for acceptance clarification.
Frequently Asked Questions
Is factory testing the same as final site acceptance?
Not necessarily. FAT occurs before shipment and checks the agreed factory scope. Site acceptance may address installation, utilities, interfaces, local material, operator training and production conditions that cannot be fully reproduced at the supplier's facility. Both stages should have separate criteria when site acceptance is required.
Must production material be used for the FAT?
Representative production material is preferred when material behavior affects the process. If another material is used, the difference should be documented and the parties should agree which results are provisional. The supplier should not claim final capability for an untested material without supporting review.
Can output be guaranteed from a short trial?
A short trial can confirm a defined cycle under observed conditions. It does not automatically represent every shift, operator, material lot or maintenance state. Output commitments should state their assumptions, and any extended performance test should be explicitly defined.
What happens when a part fails one check?
The team should first confirm the drawing revision, datum, measurement method and sample identity. The issue can then be classified as setup, tooling, material, machine, drawing interpretation or another cause. The punch list should record the correction and evidence needed for closure.
Who should attend the test?
Attendance depends on project scope. The buyer should include people who can decide technical acceptance and clarify production needs. The supplier should have representatives who understand the machine, tooling, process and documentation. Approval authority should be named before testing.
Related Machines
The evaluation method applies to CNC Tube Bending Machines, NC Tube Bending Machines, Tube Cutting Machines, Tube Punching Machines, Tube End Forming Machines and Tube Chamfering Machines. The depth of the FAT should match the actual process and agreed scope.
An integrated line may require additional interface and sequence checks, while a standalone machine may use a narrower protocol. In both cases, suitability depends on the submitted part, material, tooling and acceptance definition.
Send Your Drawing
Send the controlled finished-part drawing and project requirements for a documented review. Include tube material, shape, outside diameter, wall thickness, bending radius, required output, planned variants and proposed acceptance criteria. Ask for an assumptions list, process flow, scope matrix and draft FAT plan before dedicated tooling is released.
